Platinized Titanium Rod Anode for Pipeline Protection

clock April 6, 2022 10:00 by author admin

Platinum is an excellent anode material due to its high conductivity and low consumption rate. Due to its high cost, Platinum is made practical for use by electroplating a thin layer over a high corrosion resistance substrate. Since Titanium, Niobium and Tantalum substrates are having the ability to form an insulating oxide film under anodic conditions, they are all most commonly used as anode in ICCP.

A platinized titanium anode is simply a titanium anode coated with platinum. These anodes act as an inert anodes and are non-consumable and long lasting. These anodes are insoluble in electrolyte where electrolysis is present. Platinized Titanium Rod are usually used in cantilever anode which is used for protecting pipeline internal, pump internal & condenser box internal for 30 years and more by applying DC current with transformer rectifier.

Applications:

  • Deep & conventional ground beds.
  • Jetties in fresh, brackish and salt-water electrolytes.
  • Water tanks.
  • Lock Gates.
  • Intake Screens.
  • Marine application

platinisedRod

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



MMO Coated Canister Anode for Underground, Aboveground Storage Tanks and Pipeline Protection

clock April 6, 2022 09:38 by author admin

Cathodic protection system is an important method of preventing corrosion in underground pipelines, storage tanks, petroleum pipelines, offshore and onshore platforms etc. Cathodic protection (CP) is a technique used to control the corrosion of a metal surface.

GI Canister anode is filled with petroleum coke fill that improvise the conductivity of MMO Coated Tube, Strip or wire where the soil not having conductivity. Petroleum coke fill with low sulfur will much suits for the high resistivity soil. Canister anodes are installed vertically besides the oil pipes to avoid corrosion and horizontally installed in Tank bottoms. After some time the GI pipes are get rusted and the petroleum coke fill will be inside the soil that keeps the conductivity.

Applications:

  • Shallow vertical and horizontal surface ground beds.
  • Underground storage tanks.
  • Above ground storage tanks.
  • Pipelines.

Canisteranode

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



MMO Coated Sled Anode for Cathodic Protection

clock March 22, 2022 10:41 by author admin

It is the big problem which often exposed of concrete structure like jetty piles in seawater is continuously corroded which we cannot stop. Corrosion on the metal resulting decline in strength which leads to reduce the life. We can avoid these corrosion by ICCP (Impressed Current Cathodic Protection).

To avoid greater losses due to sea water corrosion, it needed a protection against corrosion on the pillar. One method availability is to install the shroud or much known as piles jacketing which will be sacrificial type. But we can use MMO Anodes for these protection.

The most affected by the display is on the pillars of the affected splashes water zone or quoted. At the splash zone, the structure constant splashes of sea water, and therefore we supposed to give the subsequent strength to the anodes, since the anode is not containing much weight.

Sled Anode

Therefore we are giving concrete structure like sled anode will be used. So that the anode will be in that position where the jetty pile getting protected. These anodes are substantially withstand more than 20 years.



MMO Coated Titanium Piggy Back Anode for Cathodic Protection

clock March 18, 2022 11:56 by author admin

MMO piggyback anode is the flexible anode with a long life, which integrates the advantages of large current of MMO anode and excellent conductive performance. Due to its large current and small grounding resistance, it can be buried in the place far away from the anode structure.

Piggy pack anodes are used to protect the tank bottoms. It’s the easiest method of cathodic protection which may not need a weld at site and also easy to handle and install. Piggy pack wire anodes connected with cable by the way of Crimping and sealing with mastic and heat shrink sleeve procedure. The piggy pack anodes are inserted in the jacket with coke fill to sustain the conductivity of the anodes in the place where we install for cathodic protection.

Cathodic Protection is accomplished by applying a direct current to the tank surface of the metal, which causes the electrochemical potential of the structure to shift from a corroding state to a polarized and non-corroding state.

Piggyback wire anode

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



Manufacturing and Supply of Platinum Plated Titanium Anode for Cathodic Protection of Jetty

clock March 18, 2022 11:07 by author admin

Cathodic protection systems is to protect a wide range of metallic structures in various environments. Common applications or environment to protect is steel, water or fuel pipelines and steel storage tanks such huge oil tanks, chemical storage tanks, steel pier piles, ship and boat hulls, offshore oil platforms and onshore oil well casings and metal reinforcement bars in concrete buildings and structures.

Now-a-days impressed current cathodic protection (ICCP) systems are used to avoid replacing the cathode in years together like.  These consist of anodes connected to a DC power source, often a transformer-rectifier connected to AC power. In the absence of an AC supply, alternative power sources may be used, such as solar panels, wind power or gas powered thermoelectric generators in accordance with the CP designer.

Tiaano is the manufacturing company for many CP solutions from 2003 onwards. Our cathodic protection anodes installed in onshore and offshore platform like jetty piles, underwater bridge and many structures.

Jetty CP Anode

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



MMO Coated Titanium Tubular String Anode for Pipeline Protection

clock March 3, 2022 12:02 by author admin

Cathodic protection system is an important method of preventing corrosion in underground pipelines, storage tanks, petroleum pipelines, offshore and onshore platforms etc. Cathodic protection (CP) is a technique used to control the corrosion of a metal surface.

We, Ti anode fabricators Pvt. Ltd.is familiar in manufacturing and supplying of MMO & Platinum plated Titanium and Niobium anodes for Impressed Current Cathodic Protection (ICCP). According to the customer’s requirement we manufacture the anodes from copper cored titanium and copper cored niobium too. Our anodes are gone through the accreditation test by M/s. TWT, London as per NACE standard TMO 294-2001.Either the factory made ‘LIDA’ or ‘CPCC’ connected tubular string anodes; anode tubes; for offshore platforms protection; civil probe anodes; wire anodes, piggy back anodes, anode flex, canister pack anodes; rod anodes; strip anodes; disc anodes; tank bottom ribbon anodes; mesh ribbon anodes; discrete mesh anodes are also in our production scope.

MMO coated tubular string anodes are used to protect the pipe lines which is installed horizontal bed as well as vertical deep well with multi string /single string based on several design and field condition factors including current distribution requirements.

Applications:

·         Salt, fresh and brackish water

·         Deep well Anodes

·         Marine applications

·         Tank bottoms

·         Underground pipelines

timmotubeanode

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



Tiaano’s Platinized and MMO Coated Titanium Rod for Cathodic Protection

clock February 24, 2022 11:53 by author admin

Mixed Metal Oxide(MMO) coated titanium rod and Platinized Titanium rod anodes are to be designed & manufactured by Ti Anode Fabricators Pvt. Ltd, Chennai, India. Platinum is one of the noble group of metals also a precious metal, which has excellent catalyst materials. Platinum is conductive, chemically stable and highly resistant to oxidation and corrosion. It has a silvery-grey colour and can be polished to a variety of products.

Platinum is an excellent anode material due to its high conductivity and low consumption rate. MMO anodes have imperceptibly low wear rates and are often referred to as Dimensionally Stable Anodes as they do not change geometry over time. MMO anodes are quickly becoming the most popular impressed current anode.

Cathodic protection system is an important method of preventing corrosion in underground pipelines, storage tanks, petroleum pipelines, offshore and onshore platforms etc. Cathodic protection (CP) is a technique used to control the corrosion of a metal surface.

Platinized Titanium Rod and MMO Coated Titanium Rod are usually used in cantilever anode which is used for protecting pipeline internal, pump internal & condenser box internal for 30 years and more by applying DC current with transformer rectifier.

rodanode

Applications:

  • Deep & conventional ground beds.
  • Jetties in fresh, brackish and salt-water electrolytes.
  • Water tanks.
  • Lock Gates.
  • Intake Screens.

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



Platinized Titanium FRP Insulated Strip for Ship Hull Protection

clock February 16, 2022 10:55 by author admin

Platinized Titanium anodes take advantage of the low consumption rate and high current density. Voltages in excess of 10 Volts will result in severe pitting of the titanium core causing premature failure. Exterior protection of ships hulls - anodes in the shape of plates, discs or strips. Platinum is a least reactive metals that has remarkable resistance to corrosion, even at high temperatures.

The principle of cathodic protection is connecting an external anode to the metal to be protected and the passing of an electrical DC current so that all areas of the metal surface become cathodic and therefore do not corrode. DC current is sent through an insulated wire to the anodes buried in the soil near the articles like underground storage tank, pipeline & etc.

Platinized FRP insulated strip Anode with impressed current leads to protect the hull of the ships. Negative terminal which is connected to ship hull and positive terminal with impressed current anodes. Underwater steel structures protection like wharves, jetties, sheet pile walls and piers. Usually rod type anodes are distributed throughout the structure for protection and to give a good current distribution.

FRP Strip

Advantages:

  • Increases life of rudders, shafts, struts and propellers.
  • Anodes are light and compact for easy shipping, storage and   installation.
  • High current efficiency.
  • High anti-corrosion property & lasting working life.

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:

Pinterest, Instagram, Facebook, Twitter



Manufacturing and Supply of MMO Coated Galvanized Canister Anode for Corrosion Protection

clock February 9, 2022 09:18 by author admin

Cathodic protection system is an important method of preventing corrosion in underground pipelines, storage tanks, petroleum pipelines, offshore and onshore platforms etc. Cathodic protection (CP) is a technique used to control the corrosion of a metal surface. Impressed current systems utilize an external power source that provides protective current to mitigate corrosion activity.

MMO or Platinised coating is an excellent electrical conductor and giving well chemical stability, when it will be coated on Titanium or Niobium base, even in very low pH environments. MMO coating greatly prolong the life of the anode (low wear rate) and provide excellent chemical corrosion resistance such as acid condition.

GI Canister anode is filled with petroleum coke fill that improvise the conductivity of MMO Coated Tube, Strip or wire where the soil not having conductivity. Petroleum coke fill with low sulfur will much suits for the high resistivity soil. Canister anodes are installed vertically besides the oil pipes to avoid corrosion and horizontally installed in Tank bottoms. After some time the GI pipes are get rusted and the petroleum coke fill will be inside the soil that keeps the conductivity.

Applications:

  • Shallow vertical and horizontal surface ground beds.
  • Underground storage tanks.
  • Above ground storage tanks.
  • Pipelines.

Different types of anodes in canister anode is MMO wire, tube, mesh, strip anode which is comprised of a precious metal oxide coating applied to a titanium base. The metal oxide coating is completely stable, and does not allow the object to corrode which we need to protect.
The stable anode element passes current to a highly conductive calcined petroleum coke breeze. This backfill is well compacted inside a galvanized steel canister. To allow moisture to quickly migrate to the coke breeze for increased electrical conductivity, the MMO anode element is electrically connected to the steel canister - thereby accelerating the canister corrosion rate once the anode has been installed and energized.

Galvanised canister anode

Advantages:

  • Twice the life
  • Unbreakable
  • Light weight
  • Easier to install
  • Narrower trench
  • Easy to centralize
  • Reduce excavation and drilling cost.

For more details visit these links:

www.cpanode.com,www.tiaanostore.in,www.tiaano.com

Follow us on:





MMO Coated Titanium Tubular String Anode for Corrosion Free System

clock January 31, 2022 16:15 by author admin

Cathodic protection system is a technique used to control a corrosion of a metal surface by making it the cathodic side of an electrochemical cell. Cathodic protection is an old and effective system that prevents forming rust in metal and helps in corrosion resistant. Corrosion can be prevented by eliminating the oxygen or the positively charged hydrogen ions. Two methods are available for applying cathodic protection they are:

  • Impressed Current Cathodic Protection (ICCP)
  • Galvanic Cathodic Protection

We, Ti Anode Fabricators Pvt. Ltd., developed an extremely strong and electrically low resistance centre crimp connection, which ensures the lowest possible electrical resistance (less than 1.0 Milli Ohm) between the cables and anode tube. The Platinum group Mixed Metal Oxide coating is a crystalline electrically conductive coating that activates and enables a titanium substrate to function as an anode. Whether operating in fresh water, seawater, soil, or mud. MMO Coatings are extremely stable even in very low pH environments.

Ti’s MMO titanium tubular anodes are coated with mixed metal oxide that has an extremely low consumption rate measured in milligrams per year. Unlike other types of anodes the consumption rate of MMO anode is negligible with the dimensions of the anode element remaining virtually unchanged during the operational service life of the anode. As a result, the power required to impress current will remain the same.

mmotubularanode

Advantages:

  • Lightweight/Durable
  • High current output
  • Low cost
  • Dimensionally stable
  • High cost performance

Applications:

  • Salt, fresh and brackish water
  • Deep well Anodes
  • Marine applications
  • Tank bottoms
  • Underground pipelines

single string tube

Titanium tubular anodes are manufactured using titanium seamless tube and coated with platinum group precious metal mixed oxide coating. Titanium tubular string for pipelines are arranged in ground beds either distributed or in a deep vertical hole depending on several design and field condition factors including current distribution requirements.
